No.	Item	Specification	Unit
1	Panel Size	10.1”	inch
2	Number of Pixels	1200×RGB (3)×1920	pixels
3	Active Area	135.36(H)x216.576(V)	mm
4	Pixel Pitch	37.6(H)×112.8(V)	um
5	Outline Dimension	142.8(W)×228.2(H)×2.25(D)	mm
6	Number of Colors	16.7M	-
7	Display Mode	Transmission mode, normally black	-
8	Viewing Direction	Full viewing	-
9	Display Format	HADS	-
10	Surface Treatment	HC+Clear	-
11	Interface	MIPI	-
12	Backlight	White LED	-
13	Operation Temperature	0℃~+50℃	℃
14	Storage Temperature	-10℃~+60℃	℃
15	Weight	-	g
