No.	Item	Specification	Unit
1	Panel Size	9.66”	inch
2	Number of Pixels	480×RGB (3)×1920	pixels
3	Active Area	58.032(H)x 232.128(V)	mm
4	Pixel Pitch	0.0403(H)x RGB×0.1209(V)	mm
5	Outline Dimension	65.52(W)×248.08(H)×4.6(D)	mm
6	Number of Colors	16.7M	-
7	Display Mode	Transmission mode, normally black	-
8	Viewing Direction	Full viewing	-
9	Display Format	RGB vertical stripe	-
10	Surface Treatment	Glare	-
11	Interface	MIPI	-
12	Backlight	White LED	-
13	Operation Temperature	-20~70	℃
14	Storage Temperature	-30~80	℃
15	Weight	-	g
